APPLICATOIN
Residential, Hotel, Hospital, Office, School, Shop, Apartment
FEATURES
² Cost effective and compact structure lift designed for Residential Market
² Geared or PM Gearless Traction Machine from ThyssenKrupp or Otis Supplies
² Mitsubishi Type VVVF Door Driver
² Double 32 bits CPU Controller, Integrated technologies of Redundancy, Canbus, Modbus, and GSM communication.
² Full height light curtain door Protection
² Design knowledge refer to TKE GL, KONE MINISPACE
² Otis and ThyssenKrupp qualified suppliers of Safety Pars, Wire rope and Guide rail.
² An optimized configuration ensures a higher shaft utilization rate
² Comply to Latest EN81 European Code, CHINA CODE GB7588
² Available Option: UCMP (Protection again Car Unintended Movement ) Control- Comply to most high European Code LIFT 2014/33/EU and EMC 2014/30/EU
SPECIFICATION
|
MR TYPE PASSENGER LIFT |
Type Name |
M700R |
Product Line |
TKEGL |
Persons |
6, 8 10, 13 15 17, 18, 22 |
Rated Load ( KG) |
450, 630, 800, 1000, 1150, 1250, 1350, 1600 |
Rated Speed (M/S) |
1.0, 1.6, 1.75, 2.0, 2.5 |
Maximum Travel Height (M) |
60 90 90 125 125 |
Machine Location |
Above |
Machine Type |
Geared; Gearless |
Suspension |
1:1; 2:1 |
